REL-FEE3TU23-ROCKWELL, RELAY TIMING SPDT 24-48VDC 0.05s - 10H, RELAY TIMING, 24VDC 1KONT.(SPDT)

Number of outputs, delayed, change-over contact: 1
Voltage type for actuating: AC/DC
Rated control supply voltage at AC 50 Hz: 24 V
Rated control supply voltage at AC 60 Hz: 24 V
Rated control supply voltage at DC: 24 V
Type of electric connection: Screw connection
Input current - Pulse control B1: 1 mA
Input voltage - Pulse control B1: supply voltage range
Switching capacity: Resistive load: 5 A @ 250V AC, AC-1 (IEC 60947‐5‐1)
Electrical life cycle: 400000 at 1 A/250V AC, resistive 400000 at 0.5 A/250V AC, cos φ = 0.4 400000 at 1 A/24V DC, resistive
Nominal current: 5 A
Suitable for DIN rail (top hat rail) mounting: Yes
Weight 60 g
Shock resistance: 50 g according to IEC 68-2-27
Vibration resistance: 4 g in three axes at 10...500 Hz, test FC according to IEC 60068-2-6
Suitable for front mounting: No
With plug-in socket: No
Ambient temperature storage: -40...85 °C
Mounting: For surface mounting in any position, snap-on mounting on 35 mm DIN rail or by adapter and two screws (M4 type)
Pluggable on auxiliary contact block: No

Šifra: 116485

Količina: 0

Kataloški brojevi: 700-FEE3TU23,FEE3TU23

Zamjena:
