REL-RM805024-TE CONN, RELAY 24VDC 2X25A/250VAC-INDUSTRIJSKI, 24VDC 2KONT.(DPDT), RELAY INDUSTRIJSKI

Manufacturer TE Connectivity
Relay type electromagnetic
Contacts configuration  DPDT
Rated coil voltage 24V DC
AC contacts rating
(at resistance load) 25 A / 250 VAC
DC contacts rating
(at resistance load) 25 A / 30 VDC
Contact current max. 25A
Switched voltage max 440V AC, max 300V DC
Relay variant industrial
Mounting holders
Relay series RM8
Operating temperature -45...40°C
Body dimensions 38.5 x 38.5 x 58.5mm
Coil resistance 475Ω
Mechanical durability 100000000cycles
Operate time 15ms
Release time 15ms
Coil current 50.5mA
Switching capacity 6000VA
Contact material AgCdO
Coil power consumption 1.2W
Weight 81g
Leads 6.3x0.8mm connectors

Šifra: 115588

Količina: 1

Kataloški brojevi: RM805024

Zamjena:
