ST-SPOJNICA-5, BUTT KONEKTOR 0,5-1,5mm2 SKUPLJAJUĆI, KONEKTORI, STOPICE ZA KABEL

Insulated shrinkable Butt connector to connect cables.

Shrink ratio 3:1

Mechanical characteristics:
Tensile strenght: min. 16MPa
Elongation: min. 200%

Thermic characteristics:
Heat Resistance: (168 h at 158 °C) no cracking, flowing or dripping of outer wall
Heat Shock: (4 h at 250 °C) no cracking, flowing or dripping of outer wall
Low Temperature Flexibility: 4 h at -30°C no cracking
Minimum shrink temperature: 80°C
Operating temperature: - 55°C bis + 125°C



Technical Details

Type: Butt connector with heat shrink tube
for diameter: 0,5-1,5mm²
AWG: 22-18
Dimension (mm): B= 1,7, L2 = 15, W = 4,8, L1 = 36,5
Contact material: Copper
Insulation: Full insulated
Insulation material: PE
Color: red

Šifra: 125941

Količina: 40

Kataloški brojevi: 17169MX

Zamjena:
